LEGEND 3015-S

LEGEND 3015-S LASER CUTTING

Legend 3015-S

Lightweight and Intelligent Cutting Head

Laser Cutting Examples

LEGEND 3015-S

With auto focus , thin and thick sheets can be cut at the best quality.

Single part welded body, capable of handling very high acceleration.

Auto pallet changer.

Low operational cost and energy consumption.

Excellent results for all types of materials.

Cutting with compressed air for thin sheets.

World recognized high quality components.

Automatic sheet metal loading and unloading system.

Modern and compact design.

Efficient and user-friendly structure.

Catalog

Legend 3015-S

1KW – 2KW – 3KW – 4KW – 5KW – 6KW – 8KW Laser power options available. Legend 3015-S is a unique machine having low energy consumption and very fast cutting capability with minimum maintenance cost. Legend 3015-S lazer machine has high productivity and upper segment standards. Dust collection covers are opened and closed according to the position of the cutting head. At the same time, it ensures that there will be no exhaust fumes or smoke release into the working environment. The shuttle table system is designed to increase workflow, to allow easy placement of material and to reduce time spent unloading parts. The angle of the plate and its corner are found automatically by using 3-point detection method on the plate. Fiber Lasers are inherently made for maintenance free production. The importance is sustainable diode life lasting approximately 100,000 hours.

Standard Equipment

• IPG Resonator
• 19 inch LCD touch screen
• Metalix Software
• Precitec cutting head
• Shuttle table
• Chiller laser cooling system.
• Automatic gas selection system
• Smoke suction filter
• Air conditioner for automation panel
• Slag car for interrupted parts.
• Automatic sheet measurement vision system (Camera based)
